Broadband Carrier Communication Module
It enables high-frequency electrical data acquisition, sensor data collection, and intelligent switch control.
- Overview
- Recommended Products
1. Supports 4 available Frequency Bands, with strong Anti-Interference Capabilities.
2. Communication Rate can reach 2MHz, with Business-Leyvel response within seconds.
3. Communication coverage has a wide radius, with a point-to-point distance of 300-500m and supports 16-level relay forwarding.
4. Equipped with characteristic current transmission function, suupports Physical Topology Identification of Low-Voltage distribution areas.
| Technical Specifications | Parameter Value |
| Communication Frequency Band | 0.7～12MHz |
| Communication Rate | <2Mbps |
| Modulation Scheme | OFDM |
| PLC Attenuation Resistance | 106dB |
| Communication Distance | Point-to-Point 300-500m |
| Communication Latency | ≤20ms |
| Service Life | ≥15 Years |
| Operating Voltage | AC220V、DC750 |
| Environmental Temperature | -45℃~+85℃ |
